6L 200bar CO2 Argon Tanks Nitrogen Helium N2O Air Cylinder

  •  HS
  •  Fremstillet i Kina
  •  15 til 30 dage
  •  Årlig produktion på mere end 800.000 stykker

6L 200bar ISO9809-1 CO2 cylinder Argon nitrogen helium N2O cylinder
When using high pressure cylinders, the operator should stand perpendicular to the cylinder interface. It is strictly prohibited to knock during operation, and check whether there is air leakage frequently, and pay attention to the pressure gauge reading.
A 6-litre oxygen tank; 34CrMo4 alloy steel; ISO9809-1 standard; TPED working pressure is 200bar; Hydrostatic test pressure is 300bar; 140mm cylinder outer diameter;
Oxygen or hydrogen cylinders should be equipped with special tools, and do not contact with oil. Operators should not wear clothes and gloves that are stained with grease or prone to static electricity to avoid burning or explosion.
The height of the 6-litre nitrogen cylinder is 516mm; Cylinder mouth threads include PZ27.8,25E; 3/4-14 NGT, etc.; Maximum gas storage is 1.2m3 (1,200 litres); The minimum design wall thickness of the cylinder is 3.1mm; The 6-litre cylinder weighs 7.56kg;
Alias:6L 200barCylinders ； 6L 200bar Gas Tanks,Oxygen Gas Tanks,TPED Nitrogen Gas Tanks,200bar Air Gas tanks; 6litre 200bar gas cylinders; 6litre 200bar gas bottles; 6litre 200bar gas tanks;
Flammable gas and combustion gas cylinders, and open fire distance should be more than 10 meters (really difficult to reach, isolation measures can be taken).

Kategori:

6L 200bar CO2 Argon Tanks Nitrogen Helium N2O Air Cylinder

1 、 Mindste ordremængde: Kun 100 stk.

2 、 Brug af cylindre: Vores sømløse stålcylindre bruges i vid udstrækning i industrien, medicinsk udstyr, brandbekæmpelse og videnskabelig forskning

3 、 Produkter kan eksporteres til lande eller regioner: Kina, Sydøstasien, Mellemøsten, Asien, Afrika, Europa, Oceanien, Amerika

4 、 Fabrik (vi er producenten) ：Shandong Hongsheng Pressure Vessel Co., LTD

5、 Common nonconformance points in gas cylinder production

— Manufacturing celebrities of cylinders:

a/Lamination:Layering of the material within the cylinder wall and sometimes appearing as a discontinuity, crack lap or bulge at the surface (see Figure A.5)

⎯ Inside imperfection: all cylinders with such imperfection

⎯ Outside imperfection: all cylinders with such an imperfection

6、The influence of sulfur

Sulfur is a harmful impurity that has a negative effect on the weldability and plasticity of steel. Sulfur exists in the form of iron sulfide (FeS) or manganese sulfide (MnS). Iron sulfide and iron can form eutectic with low melting point (melting point is 985℃), which is lower than the hot working temperature of steel, resulting in cracking during hot working.

In the process of hot processing, manganese sulfide elongates along the rolling direction to form the so-called fiber structure, which makes the samples cut parallel to the fiber structure direction and perpendicular to the fiber direction show a great difference in mechanical properties.

The fiber structure also affects the banded structure of rolled steel.

Similarly, the hot crack of weld in the melting zone is mainly related to the content of sulfur in the weld metal.

7、6 litre Gas Cylinder Product Parameters table (ISO9809-1 TPED 200bar)

6L 200bar CO2 Argon Tanks Nitrogen Helium N2O Air Cylinder

Type Udenfor

Diameter

(mm)

 Vand

Kapacitet

(L)

 Flaske

Højde

(mm)

 Vægt

（kg）

 Arbejde

Tryk

（Bar）

 Design væg

tykkelse

(mm)

 Materiale

Karakterer
WGⅡ140-6.0L-200 140 6.0 516 7.56 200 2.43.8 34CrMo4
