3L 200bar CO2 Argon Tanks Nitrogen Helium N2O Air Cylinder

• Brand: HS
• Produktets oprindelse: Fremstillet i Kina
• Leveringstid: 15 til 30 dage
• Forsyningskapacitet: Årlig produktion på mere end 800.000 stykker

3L 200bar ISO9809-1 CO2 cylinder Argon nitrogen helium N2O cylinder
Gas cylinders (such as hydrogen and oxygen cylinders) filled with gases that may cause combustion or explosion after contact with each other should not be carried or stored in the same place with the vehicle, nor should they be mixed with other inflammable and explosive objects.
A 3-litre helium bottle; 108mm cylinder outer diameter; Working pressure is 150bar; Hydrostatic test pressure is 250bar; ISO9809-1; TPED 34CrMo4 alloy steel
If the cylinder body is defective, the safety accessories are incomplete or damaged, and the safe use cannot be guaranteed, it must not be sent to fill the gas, but should be sent to the relevant unit for inspection before it can be used.
The height of the 3-litre oxygen cylinder body is 440mm; Cylinder mouth threads include PZ19.2,PZ27.8; 25E; 3/4-14 NGT, etc.; The 3-liter tank has a maximum storage capacity of 0.45m3 (450 litres); The minimum design wall thickness of the cylinder is 2.9mm; The cylinder body weight is 4.96Kg;
Alias: 3L 200bar cylinders,3L 200bar gas tanks,Helium bottles,3L TPED gas cylinders,200bar Air cylinders; 3litre 200bar gas cylinders; 3litre 200bar gas bottles; 3litre 200bar gas tanks;
